Code on Screen? | KingSmith WalkingPad Error Codes Explained

You're ready to walk.

You switch on your KingSmith WalkingPad.

And instead of speed, time, or distance, the screen suddenly shows:

E01.

Or E05.

Or maybe SAFE, REST, or another message that makes you wonder whether your treadmill has just developed a serious problem.

Don't panic—and don't start taking the motor cover apart.

KingSmith and WalkingPad use error codes to tell you that the machine has detected something outside normal operating conditions. Depending on the model, this might relate to:

• Motor protection

• Communication

• Voltage

• Excess current

• Temperature

• Sensors

• Overloading

• A locked motor

• Safety-key status

• Continuous-use protection

For UAE users searching for KingSmith error codes, WalkingPad error code E01, WalkingPad E02 error, KingSmith E05 error, WalkingPad E06, KingSmith treadmill error codes UAE, WalkingPad not working, KingSmith treadmill stopped suddenly, WalkingPad SAFE error, WalkingPad REST message, how to reset KingSmith WalkingPad, KingSmith WalkingPad troubleshooting, or WalkingPad error code meaning, this guide explains what the most common messages mean and what you should do next.

But there is one rule you need to remember throughout this article:

KingSmith Error Codes Can Vary by Model

This is extremely important.

KingSmith's current general WalkingPad FAQ defines:

• E01 – Drive communication error

• E02 – Motor abnormality

• E05 – Overcurrent protection

• E06 – Motor protection

• E08 – Sensor error

• E10 / E11 – Temporary countdown codes that resume automatically

However, individual KingSmith manuals can use different definitions for the same numbers.

For example, the current MX16-series manual lists:

• E01 – Software overcurrent

• E02 – Hardware overcurrent

• E03 – IPM module overheating

• E04 – Low-voltage protection

• E05 – High-voltage protection

• E06 – Motor phase loss protection

• E07 – Motor locked-rotor protection

• E09 – Motor unable to start

• E12 – Motor overcurrent

• E13 – Overload

• E14 – Hall signal missing

• E15 – Communication fault

The R3 manual uses a very similar expanded list and also includes E16 – Module connection error.

That means:

Never diagnose a KingSmith WalkingPad based only on the error number without checking the exact model.

Your own product manual should always take priority.

KingSmith Error Codes: Quick General Guide

KingSmith's current general WalkingPad support FAQ provides this basic troubleshooting table.

KingSmith's official first step for an error beginning with E is straightforward:

Turn the treadmill off for about 10 minutes, then restart it.

KingSmith notes that some codes can appear after transportation or moving the machine and may clear after this full power cycle.

If the error returns, do not keep repeatedly resetting the treadmill indefinitely.

How to Reset a KingSmith WalkingPad Error

If your machine displays an E-code, start with this simple process.

Step 1: Stop the Workout

Do not continue trying to run while an active fault is displayed.

Step off the machine safely.

Step 2: Switch the WalkingPad Off

Use the main power switch.

Step 3: Disconnect Power

Where practical, unplug the machine from the wall.

Step 4: Wait Around 10 Minutes

KingSmith recommends about 10 minutes rather than an immediate on-off reset.

Step 5: Check the Machine

Before restarting, look for obvious problems such as:

• Belt obstruction

• Belt badly off-centre

• Something trapped underneath

• Damaged power cable

• Loose safety key

• Excessive heat

• Burning smell

Step 6: Restart

Reconnect the machine and switch it on.

If the code disappears and everything sounds normal, test it first at a low walking speed.

If the same error immediately returns, check your exact model manual and contact service rather than repeatedly forcing the treadmill to restart.

KingSmith E01 Error – What Does It Mean?

This is where model-specific information becomes essential.

Current General KingSmith Meaning

KingSmith's general WalkingPad FAQ currently defines:

E01 – Drive communication error

This suggests that the control system is not communicating correctly with the drive system.

The recommended action is:

1. Turn the machine off.

2. Wait around 10 minutes.

3. Restart.

4. Contact support if E01 returns.

But Some KingSmith Manuals Define E01 Differently

For example:

A1 Pro Manual

E01 is listed as:

Software overcurrent

MX16 Manual

E01 is also:

Software overcurrent

R3 Manual

E01 is:

Software overcurrent

This is exactly why generic online lists can be misleading.

If your A1 Pro displays E01, don't automatically assume it means the same thing as E01 on another KingSmith generation.

Check your manual.

What Is Software Overcurrent?

Overcurrent means the controller has detected electrical current outside its expected operating range.

Possible contributing conditions can include increased resistance or unusually heavy load.

Things worth checking externally include:

• Belt moving freely

• Belt isn't excessively tight

• User weight is within capacity

• Nothing is trapped beneath the belt

• Walking deck is properly maintained

• Correct power supply is being used

Do not open the controller or attempt electrical repairs yourself.

If the error continues after a normal restart and external checks, it needs professional assessment.

KingSmith E02 Error – What Does It Mean?

Again, there are two common definitions depending on the model.

General KingSmith FAQ

E02 – Motor abnormality

If it continues after the recommended restart, KingSmith advises contacting support.

Some Model Manuals

The MX16 and some other manuals define:

E02 – Hardware overcurrent

The A1 Pro also lists E02 as hardware overcurrent in certain manual versions.

So E02 may point toward either a broad motor fault or electrical protection depending on the machine.

What Should You Do if E02 Appears?

First:

• Stop using the machine

• Power it off

• Wait

• Restart

If the machine:

• Jerks

• Stops suddenly

• Makes grinding noises

• Smells burnt

• Fails to start

Do not repeatedly attempt workouts.

Persistent motor-related errors need proper service.

KingSmith E03 Error – IPM Module Overheating

Several model-specific KingSmith manuals list:

E03 – IPM module overheating

IPM refers to the power electronics controlling the motor.

In simpler language:

The drive electronics have become too hot.

This may happen after:

• Long continuous sessions

• High-load running

• Poor ventilation

• Excessive belt resistance

• Heavy user load

• High ambient temperature

For UAE users, room temperature matters.

A treadmill being used in a properly air-conditioned room is operating in a very different environment from one being used in a hot garage during summer.

How to Handle E03 Overheating

If your specific model manual identifies E03 as overheating:

1. Stop the machine.

2. Switch it off.

3. Allow it to cool fully.

4. Check that ventilation areas aren't blocked.

5. Check belt condition and lubrication.

6. Resume only after the machine has cooled.

If E03 returns quickly during normal light use, contact service.

Repeated overheating is not something you should simply reset past every day.

KingSmith E04 Error – Low Voltage or Undervoltage Protection

Some KingSmith treadmill manuals list:

E04 – Low-voltage / undervoltage protection

This means the treadmill's electrical system has detected input voltage below the acceptable range.

Possible causes may include:

• Incorrect power supply

• Poor electrical connection

• Unsuitable voltage converter

• Problematic extension lead

• Internal electrical fault

KingSmith Voltage in UAE

The UAE uses approximately 230V / 50Hz mains electricity.

Before connecting a KingSmith treadmill, check the voltage rating printed on your actual machine.

This is particularly important with imported units.

For example, some KingSmith product pages and international manuals refer to 110V models, while UAE-market products may use different electrical specifications.

Never assume two visually identical WalkingPads have identical voltage requirements.

The nameplate on your treadmill is the specification that matters.

If your machine requires a different input voltage, use only an appropriate manufacturer-approved setup.

KingSmith E05 Error

E05 is another code whose definition can differ substantially.

General WalkingPad FAQ

KingSmith currently defines:

E05 – Overcurrent protection

Some Newer / Model-Specific Manuals

MX16 and R3 documentation list:

E05 – Overvoltage / high-voltage protection

Meanwhile, the A1 Pro manual also lists E05 as overvoltage protection.

So if you search:

“WalkingPad E05 fix”

and find someone online saying E05 always means the belt needs lubrication, be careful.

That advice may be for a completely different controller generation.

What Should You Do With E05?

Check the manual for your exact model first.

If E05 is listed as overcurrent, inspect external sources of mechanical load such as:

• Belt resistance

• Excessive belt tension

• User capacity

• Obstruction

If E05 is listed as overvoltage, check the machine's required power rating and electrical supply.

Do not attempt internal power-board repair yourself.

KingSmith E06 Error

KingSmith's general FAQ defines:

E06 – Motor protection

Some manuals use a more specific definition:

E06 – Motor phase loss/motor open-phase protection

This relates to the motor or its drive system.

A normal restart is reasonable.

Persistent E06 should be serviced.

This isn't a good candidate for:

“Turn it off and on 14 times until it eventually works.”

A protection code exists because the system detected something it does not like.

KingSmith E07 Error – Motor Locked-Rotor Protection

Certain KingSmith model manuals list:

E07 – Motor locked-rotor protection

This means the controller is detecting that the motor cannot rotate as expected.

Possible external things to inspect include:

• Belt physically jammed

• Object trapped in the treadmill

• Walking belt far too tight

• Mechanical obstruction

Do not manually force the motor.

If nothing obvious is blocking the machine, professional service is the right next step.

KingSmith E08 Error – Sensor Error

KingSmith's current general FAQ lists:

E08 – Sensor error

The A1 Pro manual also uses E08 for a sensor fault.

Sensors help the treadmill understand things such as:

• Movement

• Belt speed

• Position

• System status

If the controller isn't receiving the expected sensor information, it may stop operation as a precaution.

Can You Fix E08 Yourself?

Start with the normal power reset.

If E08 remains:

Contact support.

KingSmith's general FAQ specifically recommends service assistance for persistent E08 faults.

Opening the treadmill and randomly disconnecting sensor wiring is more likely to create another problem than solve the original one.

KingSmith E09 Error – Motor Unable to Start

Some current KingSmith manuals list:

E09 – Motor unable to start

This means the controller has tried to initiate motor movement but hasn't received the expected result.

External things you can safely check include:

• Nothing is obstructing the belt

• The machine is fully unfolded where required

• Safety system is engaged correctly

• Belt isn't obviously jammed

• Correct power supply is connected

If the motor still cannot start, stop troubleshooting at the user level.

The cause could involve:

• Motor

• Controller

• Wiring

• Sensor

• Mechanical resistance

and needs service diagnosis.

KingSmith E10 Error

This one is particularly confusing because different KingSmith generations use E10 differently.

General WalkingPad FAQ

Current general support says that if the WalkingPad shows E10 or E11, it should automatically resume after the countdown.

In that situation:

wait.

You don't necessarily need to repair anything.

Older / Different WalkingPad Manuals

Some older WalkingPad documentation uses:

E10 – Motor overload protection

So once again:

model manual > generic internet list.

KingSmith E11 Error

The general FAQ groups E11 with E10 as a temporary countdown condition that should clear automatically.

However, another KingSmith treadmill manual lists:

E11 – HALL signal loss

This is another perfect example of why copying an error table from a different WalkingPad model can produce the wrong diagnosis.

If E11 appears:

1. Check your exact manual.

2. If your manual says countdown protection, allow it to complete.

3. If your manual identifies E11 as a hardware/sensor fault, follow that manual's service procedure.

KingSmith E12 Error – Motor Overcurrent

Several current KingSmith treadmill manuals use:

E12 – Motor overcurrent protection

This means the system has detected excessive motor current.

Possible external contributing factors can include:

• Excessive resistance under belt

• Heavy loading

• Over-tight belt

• Mechanical obstruction

• Prolonged demanding use

But persistent E12 can also relate to the motor/controller itself.

Restart once after checking normal maintenance conditions.

If it returns, service the treadmill.

KingSmith E13 Error – Overload Protection

The MX16 and R3 manuals list:

E13 – Overload protection

This can occur when the treadmill detects a load beyond what it considers safe.

Check:

• User weight

• Belt resistance

• Workout intensity

• Obstruction

• Maintenance

For example, the current KingSmith R3 on Athletix is rated for 120kg maximum user capacity.

The current MX16 listing states a 136kg maximum user recommendation.

The correct limit depends on the exact treadmill.

Never intentionally exceed the listed maximum capacity.

KingSmith E14 Error – Hall Signal Missing

Some newer KingSmith manuals list:

E14 – Hall signal missing

Hall sensors are commonly used to provide motor-position or speed information.

If the controller loses that signal, accurate motor control can become impossible.

This is generally not a normal user-maintenance repair.

Restart the machine once.

If E14 persists, contact professional support.

KingSmith E15 Error – Communication Fault

Several model manuals list:

E15 – Communication fault

This indicates that parts of the treadmill's electronic control system are not communicating properly.

Try the standard:

power off → wait → restart

procedure.

If the error stays:

• Record the error

• Record the model

• Record the serial number

• Contact the retailer/service team

KingSmith E16 Error – Module Connection Error

The R3 manual includes:

E16 – Module connection error

Not every KingSmith model uses this code.

If it appears on an R3-series machine and remains after restarting, contact service rather than opening the machine to inspect the modules yourself.

KingSmith A1 Pro Error Codes

The KingSmith A1 Pro provides a good example of why model-specific manuals matter.

One A1 Pro manual lists:

So if you own an A1 Pro, use this table only if it matches the documentation supplied with your exact product version.

The current Athletix KingSmith range lists the A1 Pro among its active WalkingPad models.

KingSmith R3 Error Codes

The R3 JustWalk manual uses a larger list:

The current KingSmith R3 WalkingPad listed by Athletix uses a brushless motor, KS Fit connectivity, and a 120kg user capacity.

That still doesn't mean every R3-generation controller worldwide necessarily uses identical firmware.

Use the manual supplied with your unit.

KingSmith MX16 Error Codes

The MX16 manual uses a very similar expanded protection system:

Athletix currently lists the MX16 as a foldable WalkingPad treadmill with speeds up to 16 km/h, KS Fit control, and a current listed maximum user recommendation of 136kg.

For a running-capable machine like this, motor and protection codes are particularly important.

Don't ignore repeated faults at higher speeds.

Why Does My KingSmith Say SAFE?

SAFE is usually not a fault code.

KingSmith's current support FAQ says the SAFE display means the treadmill's red safety key is not installed correctly.

Check the safety key on the handrail.

Once the safety key is correctly attached, the treadmill should be able to exit Safe Mode.

The safety key exists so the treadmill can stop quickly if it is pulled away during a fall or emergency.

Do not bypass it.

KingSmith SAFE Error Won't Go Away

If the safety key is installed but SAFE stays on:

1. Remove the key.

2. Switch the treadmill off.

3. Reattach the key firmly.

4. Restart the machine.

5. Inspect the safety-key area for visible damage.

If SAFE remains despite correct installation, contact support.

The machine may not be detecting the safety key correctly.

What Does REST Mean on a WalkingPad?

REST is another message that users often mistake for a fault.

KingSmith's current FAQ says the machine may display REST after extended continuous operation.

Current WalkingPad guidance recommends avoiding continuous use longer than approximately:

• 1 hour at a time for walking machines

• 2 hours at a time for running machines

When the protection activates:

1. Switch the machine off.

2. Allow it to cool for approximately 30 minutes.

3. Restart later.

KingSmith describes this as a protective feature intended to help extend machine life—not necessarily a malfunction.

What Does PRESS Mean on KingSmith WalkingPad?

KingSmith's current support guidance says that when PRESS appears, you can press the appropriate function key on the remote control to exit.

So PRESS is generally an instruction rather than evidence of a failed motor.

KingSmith WalkingPad Black Screen

No error code at all?

KingSmith's current support FAQ recommends checking:

If Everything Is Completely Off

Confirm the main power switch is turned on.

Also check:

• Wall outlet

• Plug

• Cable

If a Light Is On but Screen Is Black

WalkingPad suggests testing another appropriate power cable or plug where safe and compatible.

If the display still does not respond, contact support.

KingSmith WalkingPad Won't Connect to KS Fit

An app connection problem is different from a treadmill motor error.

For compatible models, KingSmith uses the KS Fit App.

If your WalkingPad isn't appearing:

• Enable Bluetooth

• Allow app permissions

• Restart the WalkingPad

• Restart KS Fit

• Keep phone close

• Disconnect another phone that may already be paired

• Use Add Device inside KS Fit

For a complete walkthrough, internally link this article to:

Connect & Walk Smarter | KingSmith WalkingPad KS Fit App Guide

WalkingPad Wi-Fi Light Flashing

Some older KingSmith / WalkingPad models also use a connection indicator for Wi-Fi or network status.

The current WalkingPad support FAQ includes a reset procedure for certain models when the device cannot reconnect to the app and the Wi-Fi indicator is flashing rapidly.

However, networking procedures vary significantly between generations.

Do not assume instructions written for an older Mi Home-based WalkingPad apply to a newer KS Fit model.

Follow your own model's networking instructions.

KingSmith Remote Control Not Working

A non-working remote doesn't automatically mean the treadmill has an electronic fault.

On several KingSmith models, a replacement or disconnected remote needs to be paired again.

Depending on the model, pairing typically involves:

1. Restarting the WalkingPad.

2. Keeping the remote close to the display.

3. Holding or repeatedly pressing the designated mode/function button.

The exact procedure varies.

Use the pairing instructions in your manual.

KingSmith WalkingPad Stops Suddenly

This is one of the most searched troubleshooting questions.

If your KingSmith suddenly stops, look at the display immediately.

Possible reasons include:

• Safety key disconnected

• REST continuous-use protection

• Overcurrent

• Overload

• Motor protection

• Overheating

• Belt resistance

• Electrical protection

• Communication fault

Also check:

• Belt lubrication

• Belt tension

• Belt alignment

• User capacity

• Power supply

If it stops repeatedly without a clear protective message, contact service.

Can a Dry Walking Belt Cause KingSmith Errors?

A dry belt creates more friction between the belt and deck.

More friction means the motor has to work harder.

That can contribute to:

• Increased motor load

• Heat

• Current draw

• Belt wear

So although lubrication does not magically fix every E-code, poor belt maintenance can contribute to load-related problems.

Use only suitable treadmill silicone lubricant and follow the exact model instructions.

Internally link to:

KingSmith Walking Pad Maintenance Guide | Keep Your Walking Pad Running Smoothly

for detailed belt care.

Can an Over-Tight WalkingPad Belt Cause Problems?

Yes.

KingSmith manuals warn that a walking/running belt that is too tight or too loose can affect treadmill performance and damage the belt.

If the belt slips:

• Adjust both rear adjustment screws gradually

• Make small equal changes

• Test again at low speed

Do not keep tightening until the belt feels like a guitar string.

Excessive tension increases roller and motor load.

How Do I Know if the WalkingPad Belt Is Too Loose?

Common signs include:

• Belt slips under your foot

• Belt pauses momentarily

• Belt feels inconsistent while walking

• Motor runs but belt doesn't respond properly

Before adjusting it, check your specific manual.

KingSmith commonly recommends small increments rather than aggressive adjustments.

What if the KingSmith Belt Moves Sideways?

If the walking belt shifts left or right:

1. Stop the treadmill.

2. Use the supplied Allen key.

3. Make small adjustments according to the manual.

4. Run the treadmill slowly.

5. Recheck alignment.

Correct belt alignment helps reduce:

• Friction

• Edge wear

• Noise

• Motor load

When Should You Stop Troubleshooting?

Some WalkingPad problems are safe for the owner to check.

Examples include:

• Safety key

• Belt centring

• Remote battery

• App connection

• Basic restart

Other problems are not DIY jobs.

Stop using the machine and contact service if you notice:

• Burning smell

• Smoke

• Electrical sparking

• Repeated motor errors

• Grinding from motor housing

• Sudden uncontrolled speed changes

• Severe overheating

• Damaged power cable

• Error returning immediately after reset

Safety beats curiosity here.

The inside of a powered treadmill is not the place to discover your hidden electrician talent.

What Information Should You Give KingSmith Support?

Before contacting support, collect:

• Exact model name

• Serial number

• Error code

• Photo of display

• Short video showing the problem

• When the problem occurs

• Approximate user weight

• Speed at which fault appears

• Whether the machine recently moved

• Purchase date

WalkingPad's current official support form specifically asks for the serial number and problem image/video because those details help diagnose the issue more efficiently.

KingSmith Error Codes and Warranty

An error code does not automatically mean your machine is permanently damaged.

Some are protection systems.

Others indicate faults that need service.

If your KingSmith WalkingPad is still under warranty, avoid opening:

• Motor housing

• Controller

• Internal wiring

unless instructed by authorised support.

Unauthorised repairs can complicate warranty claims.

Athletix currently lists manufacturer-warranty support across its KingSmith range, although exact warranty coverage should always be confirmed on the individual product.

Current KingSmith Models at Athletix UAE

Athletix's current KingSmith collection contains 40 KingSmith fitness products, including 20 Walking Pads and 9 treadmills, with 20 products shown in stock at the latest check.

Current models include options such as:

• KingSmith R2 Smart

• KingSmith R3 Hybrid

• KingSmith Z3 Hybrid+

• KingSmith Z3 Hybrid

• KingSmith MX10

• KingSmith MX8

• KingSmith C2

• KingSmith A1 Pro

The key point for error-code troubleshooting is:

Each model may use different electronics, firmware, and protection logic.

So save your manual.

You may not care about page 18 today.

You definitely will when E05 appears two years later.

How to Prevent KingSmith Error Codes

Not every fault can be prevented.

But good maintenance reduces avoidable problems.

Keep the Belt Lubricated

Follow your specific model's schedule.

Keep the Belt Centred

Correct drifting early.

Don't Over-Tighten the Belt

More tension isn't automatically better.

Respect the User Weight Limit

A treadmill rated for 100kg shouldn't routinely carry substantially more.

Let the Machine Cool

Respect REST or continuous-use protection.

Use the Correct Power Supply

Especially important with imported equipment.

Keep It Indoors

Avoid UAE summer heat, balconies, and humid storage.

Keep Dust Away

Regularly clean around:

• Motor cover

• Belt

• Side rails

• Floor beneath treadmill

Dubai dust finds everything eventually.

Related Athletix Collections

KingSmith WalkingPads & Treadmills

Use this collection for current KingSmith models, including WalkingPads, hybrid treadmills, and running-capable machines.

Walking Pads

Useful for comparing compact KingSmith WalkingPads with other under-desk and foldable walking machines.

Treadmills

Useful for customers who need a larger running treadmill instead of a walking-focused machine.

Cardio Equipment

Compare treadmills with bikes, ellipticals, rowing machines, and stair climbers.

Related Athletix Blogs

How Long Does a KingSmith WalkingPad Last?

Built to Keep Moving | How Long Does a KingSmith WalkingPad Last?

This explains how:

• Motor type

• Belt condition

• User weight

• Maintenance

• Workout duration

affect long-term WalkingPad durability.

KingSmith R1 Pro vs R2

KingSmith R1 Pro vs R2: Which WalkingPad Should You Buy in UAE?

Useful for customers comparing popular KingSmith hybrid models.

Final Thoughts

A KingSmith error code doesn't automatically mean:

“Your WalkingPad is finished.”

Many codes exist precisely because the treadmill is trying to protect itself.

KingSmith's current general guidance says the first step for an E-code is usually:

Power off → wait approximately 10 minutes → restart.

But the most important lesson from this entire guide is even simpler:

Don't assume one KingSmith error-code chart applies to every WalkingPad.

A general KingSmith FAQ may tell you:

E01 = drive communication error.

An A1 Pro, R3 or MX16 manual may tell you:

E01 = software overcurrent.

Both can be correct—for different controllers.

So when an error appears:

1. Note the code.
2. Find your exact model.
3. Check that model's manual.
4. Perform the recommended restart.
5. Check obvious external issues.
6. Stop using the machine if the fault returns.
7. Contact support with the model and serial number.

And if the display shows SAFE?

Check the safety key.

If it shows REST?

Give the machine a break.

If it smells like something is burning?

That is not the time to Google “how many more kilometres can I get out of this?” 😅

Switch it off and get it checked.

Error codes aren't there to annoy you. They're there to tell you when your WalkingPad needs attention.

FAQs

What does E01 mean on a KingSmith WalkingPad?

It depends on the model. KingSmith's current general FAQ describes E01 as a drive communication error, while manuals for models such as the A1 Pro, R3 and MX16 use E01 for software overcurrent. Always check the manual for your exact machine.

What does E02 mean on WalkingPad?

The current general FAQ describes E02 as a motor abnormality. Some model manuals instead define E02 as hardware overcurrent.

What does E03 mean on KingSmith?

On several KingSmith model manuals, E03 means IPM module overheating.

What does E04 mean on KingSmith treadmill?

Some newer model manuals define E04 as low-voltage or undervoltage protection.

What does E05 mean on KingSmith WalkingPad?

The general FAQ lists E05 as overcurrent protection, but some individual manuals define it as overvoltage protection. Check your model before troubleshooting.

What does E06 mean?

KingSmith's general FAQ calls E06 motor protection. Some individual manuals call it motor phase-loss or motor open-phase protection.

What does E07 mean?

On several KingSmith treadmill manuals, E07 indicates locked-rotor motor protection.

What does E08 mean on WalkingPad?

KingSmith generally defines E08 as a sensor fault/error.

What does E09 mean?

Several KingSmith manuals define E09 as the motor being unable to start.

What does E10 mean on WalkingPad?

The current general WalkingPad FAQ says E10 may clear automatically after a countdown. Some older/manual-specific systems use E10 differently, so check the exact model.

What does E11 mean?

The current general FAQ groups E11 with temporary countdown protection, while some other KingSmith manuals define E11 as Hall-signal loss.

What does E12 mean on KingSmith?

On several newer model manuals, E12 means motor overcurrent protection.

What does E13 mean on KingSmith?

Several newer manuals list E13 as overload protection.

What does E14 mean?

On the MX16/R3 style error system, E14 means Hall signal missing.

What does E15 mean?

E15 is listed as a communication fault in several current KingSmith manuals.

What does E16 mean on KingSmith R3?

The R3 manual lists E16 as a module connection error.

How do I reset KingSmith WalkingPad error codes?

KingSmith's general guidance is to power the treadmill off for approximately 10 minutes and then restart it. If the code persists, use your model manual or contact service.

Why does my WalkingPad say SAFE?

The red safety key is likely missing or not correctly attached.

Why does my KingSmith say REST?

REST usually indicates the machine has reached its continuous-use protection period and needs time to cool.

How long should I let my WalkingPad cool down?

Current WalkingPad support guidance recommends approximately 30 minutes after REST protection.

Why did my KingSmith suddenly stop?

Possible causes include the safety key, motor protection, overload, overcurrent, overheating, continuous-use protection, or another error condition. Check the screen immediately for a message or code.

Can lubrication fix a KingSmith error?

Lubrication can reduce belt friction and motor load, so it may help prevent certain load-related problems. It will not repair communication, voltage, sensor, or electronic faults.

Can I continue using my WalkingPad with an error code?

Do not continue exercising if an active E-code persists. Restart according to KingSmith guidance and contact service if the code returns.

Why does the same WalkingPad error code mean different things online?

KingSmith has produced multiple WalkingPad generations with different control systems and firmware. Error-code assignments can therefore differ between models.

Where is the KingSmith serial number?

Look for the machine's product/nameplate sticker. WalkingPad support asks for the serial number when handling after-sales faults.

Should I open my KingSmith treadmill to repair an E-code?

Not unless authorised service specifically instructs you to. Motor, controller, and electrical faults should normally be handled professionally.

Can an incorrect voltage cause KingSmith errors?

Yes. Some KingSmith models include under-voltage and over-voltage protection. Always use the electrical supply specified on the machine nameplate.

Can a tight belt cause an error code?

An overly tight belt increases motor load and can affect performance. KingSmith manuals specifically warn that belts that are too tight or too loose can damage performance and the running belt.

Does Athletix sell KingSmith WalkingPads in Dubai?

Yes. Athletix currently offers a dedicated KingSmith range with WalkingPads and treadmills for customers across the UAE.

Can I get KingSmith support in UAE?

If your KingSmith was purchased through Athletix, contact Athletix support with your order information, model, serial number, error code, and preferably a photo or video of the fault.
